Migrating from Cisco UCCX to Webex Contact Center? What UC Engineers Need to Know
Call center operations are evolving fast. AI-powered agents, advanced analytics, and simplified system administration are changing how organizations manage customer interactions. It is no surprise that many are moving from on-premise Cisco UCCX to cloud-based Webex Contact Center, gaining scalability, hybrid workforce support, and a platform designed for the future.
Why Call Centers Are Making the Move
Similar to the transition users have made from Cisco UCM to Webex Calling, on-prem call center users are increasingly drawn to Cisco's cloud-native contact center solution, Webex Contact Center.
While UCCX served as the industry standard for decades, organizations are discovering that its cost and inflexibility can't compete with the agility and innovation of Webex Contact Center. Built from the ground up for automation and redundancy, the platform enables agents to work securely from anywhere without complex VPN configurations, while its integration-first architecture seamlessly connects to cloud CRM systems, collaboration tools, and enterprise applications. Perhaps most compelling is the elimination of costly hardware refresh cycles and manual software upgrades, freeing IT teams and budgets to focus on strategic initiatives that drive business value rather than infrastructure maintenance.
Key Differences to Plan For
A typical migration from UCCX to Webex Contact Center takes 3 to 6 months, depending on the complexity of your environment. Here are the biggest shifts and challenges you should plan for:
Terminology & Logic Translator
Quick reference for mapping legacy terms to the new cloud architecture.
| Cisco UCCX Term | Webex Contact Center Equivalent | Key Difference |
|---|---|---|
| CSQ (Contact Service Queue) | Queue | Webex Queues are decoupled from skills, allowing logic-based routing. |
| Trigger | Entry Point / Dial Number | Entry points handle the arrival logic before the call hits a queue. |
| Script / Application | Flow | Visual flow builder replaces the complex editor; easier for non-devs. |
Mindset Shift
You no longer manage VMs or patch servers. Your focus shifts to API integrations and cloud performance. Troubleshooting happens in Webex Control Hub and browser tools, not server logs.
Visual Flows
Scripts must be rebuilt manually in the modern Flow Designer. Complex flows involving database reads now require a middleware API to bridge logic and return JSON data.
API-Driven Analytics
SQL queries are replaced by the Webex Analyzer GraphQL API. Note that Analyzer only retains 13 months of data, so external warehousing is often required.
Webex Agent Desktop
Agents move from Finesse to Webex Desktop. While intuitive, this shift requires retraining as teams adjust to the new browser-based workflows.
LAN to WAN
Performance now depends on the public internet. Jitter and packet loss can impact voice quality, making a pre-migration network assessment essential.
Historical Data
Native tools do not transfer historical UCCX reports. You must run ETL jobs to copy data to an external SQL server for long-term access and compliance.
Detailed Breakdown of Key Data Fields: UCCX vs. Webex Contact Center
The way Webex Contact Center data is structured, accessed, and reported on is fundamentally different than UCCX.
Data Field Translation Matrix
| Data Needed | Cisco UCCX (On-Premise) | Webex Contact Center (Cloud) | Why This Matters for Engineers |
|---|---|---|---|
| Historical Data Source | IBM Informix Database (db_cra) | Analyzer API (GraphQL) | You are moving from writing SQL queries against a live database to making GraphQL API calls. You must also maintain your own "off-box" SQL server for long-term UCCX historical data. |
| Custom Historical Reporting | Call.PeripheralVariable1-10 | Reportable Global Variables | This is your direct apples-to-apples comparison. WxCC is far more flexible, allowing up to 100 reportable variables of various data types that can be easily added to custom Analyzer reports. This is a major upgrade. |
| Real-Time Agent Data | Expanded Call Context (ECC) Variables | Global Variables (Viewable on Desktop) | ECC variables were for real-time screen pops on Finesse. The WxCC equivalent is a Global Variable made "viewable" on the Agent Desktop. Remember: ECCs were not for historical reporting. |
| Agent Activity Tracking | AgentStateDetail Table | Agent Activity Records (AAR) | Both track agent states. In WxCC, AARs are part of a larger, journey-centric model. You'll query the API for AARs linked to a specific contactSessionId. |
| Call Journey Tracking | Joining tables on sessionID | Customer Session Records (CSR) | WxCC's CSR model is "cradle-to-grave" out-of-the-box. In UCCX, you had to manually join tables like ContactCallDetail and ContactQueueDetail. |
| IVR Logic | UCCX Scripts (.aef) | Flows | Scripts must be manually rebuilt in the visual Flow Designer. This is your chance to refactor and simplify legacy logic. |
| Data Access | ODBC Connection to db_cra | GraphQL Search API | Your entire workflow for custom reporting changes. Instead of SQL, you'll be using API clients like Postman or writing scripts. |
| Recording & Archiving | On-premise storage, managed by you. | Cloud storage with a 13-month retention limit. | For compliance beyond 13 months, you must use the API to periodically download recordings and reporting data to your own storage. |
Setting Up Your KPIs for Success & Continuity
Your contact center managers will want to see the same KPIs they rely on today. Here’s how to map them from your UCCX to your new Webex system.
| KPI | How to Get It in UCCX | How to Get It in Webex Contact Center | What to Watch For |
|---|---|---|---|
| Service Level (SL) | From the ContactQueueDetail table, often a metServiceLevel boolean field. | A standard, configurable metric in the Analyzer, available for all queues. | Ensure the SL thresholds are configured identically in WxCC to maintain an accurate comparison. |
| Abandonment Rate | Calculated from the disposition field in the ContactQueueDetail table. | A standard metric in the Analyzer. The API provides detailed termination reasons. | WxCC's journey-centric model may capture abandons in IVR more accurately than some UCCX scripts. |
| Average Handle Time (AHT) | Derived from fields like talkTime and wrap-up data in the ContactCallDetail table. | Calculated from distinct duration fields in the API, such as connectedDuration and wrap-up time. | AHT is a standard metric in the Analyzer. Ensure your wrap-up time configuration is consistent. |
| Agent Occupancy | Calculated from the duration of various states in the AgentStateDetail table. | Calculated from the durations of agent states (Available, Idle, Engaged) captured in Agent Activity Records (AAR). | Agent state terminology may differ. Map your UCCX "Not Ready" reason codes to WxCC "Idle" codes for consistency. |
When setting up reports in the Webex Analyzer, start by recreating your key CUIC reports. Monitor these reports closely during and after migration to ensure the data trends are consistent. A sudden drop or spike in a key metric could indicate a misconfiguration in a flow or a difference in how the metric is calculated.
Common UCCX Migration Questions and Issues
What are the biggest technical "gotchas"?
- Script Conversion: The biggest hurdle is converting scripts that rely on direct database lookups or XML parsing. In WxCC, you must create a middleware API to act as a bridge. Your flow will make an HTTP Request to this API, which then queries your on-premise database and returns the data as JSON.
- Agent Login Issues: Often related to SSO configuration or network firewall rules blocking access to the Webex cloud services.
- RONA (Redirect on No Answer) Timeouts: Softphones like Jabber can sometimes have delays that cause calls to RONA prematurely. Be prepared to adjust system timers.
How is historical data handled? Can I migrate it?
You cannot migrate your UCCX historical data directly into the Webex Contact Center Analyzer. The schemas are completely different.
Workaround: The best practice is to archive your UCCX data. Set up an ETL job using an ODBC connection to the db_cra database (using the uccxhruser credentials) and pull the data into an external SQL server. This becomes your permanent archive. For unified reporting during the transition, third-party analytics tools can connect to both your archived UCCX data and the live WxCC API.
What changes for agents and supervisors?
The agent experience moves from the Cisco Finesse desktop to the modern, web-based Webex Contact Center desktop. It's a more intuitive interface but will require training.
Supervisors gain access to the user-friendly Analyzer for reporting and can manage their teams more effectively, but they will need to be trained on the new tool.
What are the networking and latency considerations?
Since WxCC is a cloud service, agent and gateway connectivity relies on a stable, low-latency internet connection. Jitter, packet loss, and high latency can impact voice quality. A thorough network assessment is a critical pre-migration step.
What about UCCX to Webex CC licensing?
Licensing moves from a perpetual, on-premise model to a subscription-based cloud model, typically on a per-agent basis. The specifics are complex and change frequently, so it is essential to work closely with your Cisco partner or account team to get an accurate plan.
Approaching Your Webex Contact Center Migration with Confidence
If you're considering a move from Cisco UCCX to Webex Contact Center, understand that it requires a strategic transformation of your contact center infrastructure. Your call flows need reconstruction for the new platform, your APIs work differently, and your reporting infrastructure changes entirely. Agent training, network optimization, and integration updates all demand attention to ensure a smooth transition.
Like any major migration, success hinges on careful planning and strategic data management. You need to preserve historical UCCX data while establishing new KPIs in Webex Contact Center—ideally with visibility across both systems without constantly switching interfaces. A third-party reporting solution like Expo XT from Metropolis Corp can simplify this significantly. By unifying data from your legacy UCCX environment and new Webex Contact Center platform, Expo XT eliminates reporting gaps and maintains KPI continuity throughout your migration and beyond.
Don't lose your 5 years of UCCX history. Learn how Metropolis' Expo XT blends your legacy UCCX reports with your new Webex data in one dashboard.
